Impeller & Seal Kit for Circulation Pump, TheraMax II, 1/15hp, 230v, Sundance or Jacuzzi, 02410512-2 or 6500-907

This Impeller and Seal Kit is used ONLY in Intertek Impeller & Seal Kit for Circulation Pump, TheraMax II, 1/15hp, 230v, Sundance or Jacuzzi, 02410512-2 or 6500-907 Pumps Only. The impeller may have the number B706-01, B706-02, B706-03, B706-04, B706-05 on the back. The impeller measures about 3 5/8" across but the size can vary but this impeller is the only choice for a WTC50 of any style. It is 1 39/64" Across the back of the Spring Seal part that goes into the volute or wet end back and the Ceramic & Rubber part that goes into the impeller is 1 11/32". The Hole in the ceramic part is about 3/4" and the hole in the spring side measures about 45/64".

Note: We have no idea what bearing is in this pump motor so if you need a bearing replace the complete pump and motor..
